Use Case: API Access

• Why would you want to do it?
  • Web apps: Web frontend + REST access to backend
  • Cloud services:
    • Create Openstack VM from commandline
    • Access storage
    • Github
    • …
• Protect your REST API with OIDC: => flaat
• Access a REST API with OIDC: => oidc-agent + curl

Use Case: Grid

• X.509 => Tokens
• All use cases from grid should work with tokens:
• Service migration -> Service developers => flaat
• How does the user get tokens => oidc-agent
• But: can we just replace X.509 certificates with tokens?
  • Tokens cannot be revoked
  • Tokens (should) live much shorter
  • Long-running jobs need fresh tokens
    • => Look at mytoken

Use Case: Shell Access

• I started my Openstack VM, now what?
  • I need to access remote services (e.g. using tokens) => access tokens
  • I need an access token throughout the lifetime of the VM => mytoken, maybe vault
• Similar for HPC
  • I need to ssh into my HPC-cluster / VM => ssh-oidc/motley-cue

Getting access tokens

# Example:
# Step 1: Obtain a refresh token from your issuer:
    oidc-gen --pub --iss https://wlcg.cloud.cnaf.infn.it  --scope "eduperson_entitlement email" wlcg-demo
        <follow the flow in your browser ...>

# Step 2: Get access tokens:
    oidc-token wlcg-demo

# Step 3: Take a look at the token, and the userinfo endpoint:
for T in $(oidc-token wlcg-demo| tr '.' '\n' ); do
    echo $T | base64 -di 2>/dev/null | jq --indent 4 2>/dev/null
done

# Step 3: Or just do it in python
    pip install flaat
    flaat-userinfo `oidc-token wlcg-demo`

                                          Result

Information stored inside the access token:
{
    "body": {
        "aud": "https://wlcg.cern.ch/jwt/v1/any",
        "client_id": "c44fc787-b3f8-483d-a78b-22c29fd4e524",
        "exp": 1679973409,
        "iat": 1679969809,
        "iss": "https://wlcg.cloud.cnaf.infn.it/",
        "jti": "36932e6e-44d9-4688-b867-f7a4fd76f2ad",
        "nbf": 1679969809,
        "scope": "openid offline_access profile eduperson_scoped_affiliation eduperson_entitlement email wlcg wlcg.groups",
        "sub": "61a5aa12-27c8-41c1-b05b-9eb6f724d29f",
        "wlcg.groups": [ "/wlcg" ],
        "wlcg.ver": "1.0"
    },
    "header": { "alg": "RS256", "kid": "rsa1" },
    "signature": "Jysd5TXn0iTbaPkjXKjjnVdM9ae5y8J4LK_jdUX-m5JmvE1d_njzq151tE629lmYjKqC0AOF88dShG2efJ7d1saFBIQ3sV50otvbSSDC81BAFLqznecS_FmbpI33GIt0gsSmcpSVbcibMum4lT_S0MUbCL-cmx_M5TvmhI2wbMk",
    "verification": {
        "algorithm": "RS256"
    }
}

Information retrieved from userinfo endpoint:
{
    "email": "marcus.hardt@kit.edu",
    "email_verified": true,
    "family_name": "Hardt",
    "given_name": "Marcus",
    "iss": "https://wlcg.cloud.cnaf.infn.it/",
    "name": "Marcus Hardt",
    "preferred_username": "marcus2",
    "sub": "61a5aa12-27c8-41c1-b05b-9eb6f724d29f",
    "updated_at": 1595850339,
    "wlcg.groups": [
        "/wlcg"
    ]
}

More fun

flaat

https://flaat.readthedocs.io

• Authorisation for REST APIs
• Flexible python framework
  • Supports flask, AIO, FastAPI

# Example Code (skipping boilerplate)
@routes.get("/authorized_vo")
@flaat.requires(
    get_vo_requirement(
        [
            "/wlcg",
            "/cms",
        ],
        "wlcg.groups",
        match=1,
    )
)
async def authorized_vo(request):
    return web.Response(text="This worked: user has the required entitlement")

# Example call and response
marcus@nemo:~$ http http://localhost:8080/authorized_vo  "Authorization: Bearer `oidc-token wlcg-demo-delme`"
HTTP/1.1 200 OK
Content-Length: 46
Content-Type: text/plain; charset=utf-8
Date: Tue, 28 Mar 2023 02:40:39 GMT
Server: Python/3.11 aiohttp/3.8.3

This worked: user has the required entitlement

What else?

mytoken [1/2]

https://mytoken.data.kit.edu

• What if you have a long-running job
  • … that also spends some time in a queue
• mytoken (think “myProxy” done right)
• Solves this!
• mytoken-server:
  • gets the refresh token (typical web-flow)
  • encrypts + stores refresh token with mytoken
  • returns the mytoken-token to user
• user (client):
  • use the mytoken with mytoken-server to get access token

mytoken [2/2]

• Why is it better than sending refresh-tokens with the job?
• Features to carefully balance security requirements with use case:
• Capabilities
  • WHAT can the mytoken do (get ATs, create new MTs, history, introspection, settings, …)
• Restrictions
  • LIMITATIONS on the token are based on
    • time, IP address space, geolocation, number of usages, scopes, audiences
• More info: https://mytoken-docs.data.kit.edu
• Example: https://mytoken.data.kit.edu
• Using mytoken client from the cmdline

$ mytoken AT --MT $MYTOKEN
eyJ[............]

Combining these solutions….

…for SSH with federated identities

SSH

Kind of holy grail, because:

• Use federated identity
  • SSH-Server has no direct relation with Organisation where user comes from
• To log into a Unix account
  • How to find the correct unix account?
• Authorised by
  • Virtual Organisation membership (entitlement)
  • Assurance
  • Individual user (sub + iss)
• How to revoke access?
  • User gone
  • Security incident

Approaches

flaat + pam-module

• PAM Module pam-ssh-oidc developed by PSNC (in Pracelab.PL)
• pam-ssh-oidc enables two things:
  1. Prompt for “Access Token”
  2. Put access-token into ssh password field
• pam-module uses flaat for authorisation
• Prerequisite: the remote user has to exist










# Example
$ oidc-token google # or mytoken AT --MT $MYTOKEN
$ ssh cool001@ssh-oidc-demo.data.kit.edu

(cool001me@ssh-oidc-demo.data.kit.edu) Access Token:
(cool001me@ssh-oidc-demo.data.kit.edu) Password:
(cool001me@ssh-oidc-demo.data.kit.edu) Access Token:

cool001me@ssh-oidc-demo:~$

flaat + pam-module + motley_cue

https://motley-cue.readthedocs.io

• motley-cue: Server-side daemon developed in HIFIS (Germany)
• motley-cue fixes 4 things:
  1. Dynamically provision a user (plugin-based, optional)
     • Pooled-account, “Friendly” username, External username lookup
     • Authorisation based on
       • entitlement (i.e. VO)
       • assurance
       • sub@iss (user whitelist)
  2. If access token is longer than 1kb
     • motley_cue creates a one-time-password (OTP)
  3. Obtain the username from server for you
  4. Admin interface for security incidents
     • suspend / resume user
  • But opens a REST interface on the server







# Example
mccli ssh ssh-oidc-demo.data.kit.edu --oidc wlcg-demo

cool001@ssh-oidc-demo:~$

SSH notes

• No ssh-daemons (or clients) were hurt in this project:
  • Unmodified SSH Client and Server
  • Backward compatible with: password, ssh-keys, 2nd factor modules, …
• mccli
  • wrapper around unmodified client:
  • oidc access token handling (via oidc-agent)
  • Currently supports:
    • ssh, scp
    • more to come
• Demo: https://ssh-oidc-demo.data.kit.edu
• Windows Client available: http://repo.data.kit.edu/windows/oidc-agent/
  • Use plugin of putty
  • Plugin supported by oidc-agent for windows available here
• Supported platforms
  • Windows: Putty
  • Mac/Linux: OpenSSH
• Packages: https://repo.data.kit.edu
• Video: https://youtu.be/090D4s0TNaA
• Visit https://ssh-oidc-demo.data.kit.edu to try it yourself

More SSH Approaches

• Multiple different approaches exist
• Smart Shell
  • AWI, SURF
• SSH Certificates
  • DEIC
• PAM Module
  • STFC, KIT











That’s all

Orpheus

https://orpheus.data.kit.edu

• Gain deep insights
  • into everything

https://orpheus.data.kit.edu

Motely-cue Architecture

KIT SSH-OIDC: Installation

• Package installation:
  • Server: apt-get install motley-cue pam-ssh-oidc
  • Client: pip install mccli
• Configuration:
  • PAM Module: /etc/pam.d/sshd
  • [Authorisation / Supported OPs: /etc/motley-cue/motley-cue.conf]
  • [Provisioning: /etc/motley-cue/feudal.conf]
