Motivation

• Use benefits of federated identity management with ssh
  <=> Enable using ssh with eduGAIN login
• Reduce need for ssh-keys
  • Often not encrypted
  • Sometimes shared
  • Cumbersome provisioning processes (upload via web)
• Improve life of operators
  • Scaling is hard: key approval and distribution
  • User offboarding difficult (key binding is permanent)
    • ssh-keys live forever
• Fix ssh annoyances:
  • SSH-keys trusted permanently
  • SSH-keys can be shared across devices or teams
  • SSH-key passphrase cannot be enforced

Recap: Federated Identities

• Home Organisation (university, institute)
  • Authoritative source of
    • Identifier, Name, Contact Information
    • Affiliation with the institute
    • Basic Entitlements
    • Identity Assurance
• Community AAI
  • Delegated authorisation:
    • Community Group Membership (Entitlements)
    • Direct community authorisation (Entitlements)
  • Better defined set of attributes

Federated Identities [2/2]

• As a user
  • Single Sign-On (SSO)
  • No additional service credentials
    => Increase in security
  • Less prior registration
    => Increase in convenience
• As a service
  • Offload identity management to home organisation
  • Offload authorisation management to Community AAI (VOs)
    => Reduce cost
    => Improve user data quality
    => Service is provided to a VO (not to an individual user anymore)
  • Improved security
    • Well defined incident response
    • Federated Security Operations

ssh vs federated-IDs

Map federated IDs to
Unix accounts

Why on earth?

1. We already have information about the federated user
   • Federated ID is conveyed via the OIDC Access Token
2. We already have authorisation information in the federated information


• The world consists of thousands of Unix servers
  => We do not want to memorise different Unix accounts for each server
  (hundreds!!)
  • Nobody wants to memorise all those accounts

How do we map federated ID to local Unix account

• motley-cue: https://motley-cue.readthedocs.io
  • Server-side REST interface developed in HIFIS (Germany)


• Check authorisation
  • Based on entitlement (i.e. VO) + assurance + sub@iss (user whitelist)
• If authorised: return mapped Unix account
  • If mapping exists
    • Fine, we’re done
  • If mapping does not exist (Optional)
    • Dynamically provision a user
      • Pooled-accounts, “Friendly” username, External username lookup
    • Multiple provisioning backends
      • Local, LDAP, Ticket-System
• Admin interface for security incidents
  • Suspend / Resume user

Cornerstones for KIT SSH-OIDC

• Use federated identity
  • SSH-Server has no direct relation with Organisation where user comes from
• Use federated authorisation
• Support for revocation (deprovisioning / offboarding)


• Create an ecosystem of components for ssh
  • Easier to support different use-cases
• Don’t modify ssh
  • Patching ssh would result in forking => No

Make ssh use Access Tokens

• PAM (Pluggable Authentication Module)
  • Standard Unix interface
  • Simple + well understood
  • Change the user prompt of ssh: Password -> Access Token
  • Verify Access Token
• Packages available for most Linux distributions
  • pam-ssh-oidc  +   pam-ssh-oidc-autoconfig
  • debian, ubuntu, centos, alma, fedora, rocky, SuSE, Arch
• User sends Access Token instead of password:

$ ssh testuser@ssh-oidc-demo.data.kit.edu
(tetsuser@ssh-oidc-demo.data.kit.edu) Access Token:

Get Access Tokens

• oidc-agent: https://indigo-dc.gitbook.io/oidc-agent
  • Just like ssh-agent
• Pros:
  • Secure
  • Easy to use
  • Largely non-interactive
• Cons:
  • Requires installation on (own) ssh-client computer

Map fed. User to Unix account

• motley-cue:small>https://motley-cue.readthedocs.io
• Client calls motley-cue before ssh
  => get the unix username
• Only issue:
  • Opens a REST interface (on a server close to sshd)







Map federated user: client side

New tool: mccli

• Automation of client-side tasks:
  • Obtain Access Token via oidc-agent
  • Get username for ssh server
    • via motley-cue REST interface
  • Put Access Token or OTP into password field

# Example
$ mccli ssh ssh-oidc-demo.data.kit.edu --oidc kit.edu

testme@ssh-oidc-demo:~$

Usability Optimisation [1/2]

• Run client side in web browser
  • Get the Access Token
  • Fix software installation requirements
    • Ported mccli to javascript
• Simple web login (authorization-code-flow)
• Result: web-shell in your browser
• Example: https://ssh-oidc-web.vm.fedcloud.eu

What is still missing

• Advanced usage of ssh:
  • Tools on top of ssh: rsync, git
  • Advanced commandline: dd if=/dev/sda | pbzip2 | ssh fileserver "cat - > backup.img.bz2"
• Reduce dependency on client-side components
  • mccli: Find a way to drop it
  • oidc-agent: if needed once per month, a web copy+paste flow is viable.

Recap: ssh-certificates

• Introduced with openssh-v5.3 in 2010
• ssh-certificates are not X.509
• ssh-ca signs: host keys + user keys
• ssh-certificates expire :)
• SSH server admin trusts CA to issue certificates only to trusted users!
• Different usage:
  • Provision public keys -> Provision ssh-ca keys

ssh-certificates

• Certificates are ssh-keys, but with trust-chain
• Certificates allow similar features as ssh-keys
  • principals, => list of valid user names
  • force-command, => allowed command for certificate-user

$ ssh-keygen -L -f user-key-cert.pub
user-key-cert.pub:
    Type: ssh-ed25519-cert-v01@openssh.com user certificate
    Public key: ED25519-CERT SHA256:rkSKv...
    Signing CA: ED25519 SHA256:xw9aV... (using ssh-ed25519)
    Key ID: "whatever"
    Serial: 0
    Valid: from 2023-09-01T14:30:00 to 2023-09-02T14:30:00
    Principals:
        oinit
    Critical Options:
        force-command oinit-switch marcus
    Extensions:
        permit-X11-forwarding
        permit-agent-forwarding
        permit-port-forwarding
        permit-pty
        permit-user-rc

oinit

New components to integrate ssh-certificates with motley-cue

• oinit-ca, an online ssh-ca
  • With REST interface (protected with OIDC)
  • Authorisation (via motley-cue):
    1. CA: Authorisation based on OIDC claims
    2. motley-cue: Find unix username for federated user
    3. sshd: Ensure a local user exist for federated ID
  • Optional Provisioning
    • oinit-ca supports provisioning via motley-cue
• oinit openssh: serverside components to support oinit
  • Mapping of federated ID -> local unix account

oinit client side

• oinit:
  • Helper tool to configure ssh to use oinit for selected ssh servers
  • Define which ssh-servers support oinit
    • … and which oinit-ca to use
    • Once per computer lifetime
  • oinit add <ssh-server>[:<port>] http[s]://<ssh-ca>[:<port>]
• Purpose of configuration:
  • Obtain ssh-certificate whenever needed
    • e.g. expired, deleted, …
  • oinit mechanism is then used via ~/.ssh/config

Actual ssh call

• On first call to oinit-enables ssh-server, openssh-client will
  • Prompt user for oidc credentials
    • e.g. via oidc-agent or mytoken
  • Store ssh-certificate in ssh-agent
  • Refreshed once per ssh-certificate lifetime:
  • And do ssh:











$ ssh ssh-server.edu

[1] https://aai-dev.egi.eu/auth/realms/egi
[2] https://aai.egi.eu/auth/realms/egi (Accounts: egi)
[3] https://accounts.google.com
[4] https://iam.deep-hybrid-datacloud.eu
[5] https://login-dev.helmholtz.de/oauth2
[6] https://login.helmholtz.de/oauth2
[7] https://oidc.scc.kit.edu/auth/realms/kit
[8] https://wlcg.cloud.cnaf.infn.it
? Please select a provider to use [1-8]: 2
✔ Received a certificate which is valid until 2024-03-08 14:04:20

Future work

• Fix packaging
  • Not all tools interoperate out of the box just yet
  • debian, ubuntu, centos, alma, fedora, rocky, SuSE, Arch
• Provide consistent documentation of our Ecosystem
• Further integration
  • e.g. with Account LInking SErvicE  (ALISE)
• Security Audit
• oidc-agent forwarding
• Policy: More entries on the “How-long-should-an-xxx-live?” list:
  • X.509
  • Access Token
  • Refresh Token
  • mytoken
  • ssh certificate

Summary

• No ssh-daemons (or clients) were hurt in this project:
  • Unmodified SSH Client and Server
  • Backward compatible with: password, ssh-keys, 2nd factor modules, …
• Supported platforms
  • Windows: Putty
  • Mac/Linux: OpenSSH
• Packages: https://repo.data.kit.edu
• Video: https://youtu.be/090D4s0TNaA
• Visit https://ssh-oidc-demo.data.kit.edu to try it yourself

More SSH Approaches

• Multiple different approaches exist
• Smart Shell
  • AWI, SURF
• SSH Certificates
  • DEIC
• PAM Module
  • STFC, KIT











That’s all

Orpheus

https://orpheus.data.kit.edu

• Gain deep insights
  • into everything

https://orpheus.data.kit.edu

Motley-cue Ecosystem

KIT SSH-OIDC: Installation

• Package installation:
  • Server: apt-get install motley-cue pam-ssh-oidc
  • Client: pip install mccli
• Configuration:
  • PAM Module: /etc/pam.d/sshd
  • [Authorisation / Supported OPs: /etc/motley-cue/motley-cue.conf]
  • [Provisioning: /etc/motley-cue/feudal.conf]
