naco
The “N” Attribute COnformity checker

Marcus Hardt, Gabriel Zachmann

Mar 2025

Technical Overview

Motivation

Why am I showing this in here in Taiwan / Asia?

  1. Interoperability!
  2. Interoperability!
  3. Interoperability!

Global Interoperability!



AARC BPA













Context

  • Federated Identity Management in Research
    • Community AAIs Collaboration Management Platforms
      • act as proxies between IdPs and services
    • Services require consistent user attributes for access control
  • Attribute Compliance Challenges
    • Different Community AAIs may release attributes inconsistently
    • Community AAIs forward attributes from IdPs with varying quality
    • No automated tooling to continuously verify compliance
  • Risk: Lack of interoperability across research infrastructures

Service Interoperability

  • Inconsistent attributes make service development more complex
  • This leads to: less services / bad user experience
  • Which threatens the success of independent ID-Management in science



How does naco help?

  • Validate attribute release
  • Focus is on OIDC tokens
    • SAML assertions can be uploaded via API
  • Continuously monitors many Community AAIs
  • Your AAI HERE!!!

Drop me an email: hardt@kit.edu

naco Features

Supported Specifications

  • AARC-G056 (Draft)
    • AARC Attribute guidelines
    • Interoperability requirements for federated access
    • Community-defined attribute expectations
    • Defines basic and extended attribute sets
  • NFDI Attribute Profile
    • Attribute requirements
    • Based on an early draft of AARC-G056
    • Additional optional attributes

Attribute Specification System

  • Make use of Attribute Catogories
    • Example: Name
      (flaat-userinfo --oidc login | grep -Ei "(marcus|hardt)"
      • “display_name”: “Marcus Hardt”,
      • “family_name”: “Hardt”,
      • “given_name”: “Marcus”,
      • “name”: “Marcus Hardt”,
      • “preferred_username”: “marcus”,
      • “sn”: “Hardt”,
    • naco (actually G056 likely) is happy, if a name is found

Where naco gets information

  • OIDC
    • User Info endpoint
    • Access Token body
    • Token Introspection
  • Validation Checks
    • Attribute presence (single or compound keys)
    • Type correctness (string, list, bool, dict)
    • Scope correctness (external vs community scopes)
  • Result Generation
    • Per-attribute and per-source results
    • Summary verdict per Community AAI
    • Colour-coded: green=OK, red=missing/error

Attribute Sets

  • Mandatory Attributes (Basic Set)
    • Identifier (sub+iss, eduperson_unique_id, voperson_id)
    • Name information (name)
    • E-Mail (email, voperson_verified_email)
    • Home organisation affiliation (voperson_external_affiliation)
    • Assurance levels (ass, assurance, eduperson_assurance)
  • Optional Attributes (Extended Set)
    • Groups and roles (eduperson_entitlement)
    • Capabilities (entitlements (eduperson_entitlement)
    • Agreement to policies (voperson_policy_agreement)
    • ORCID identifier (orcid)
    • Preferred email (voperson_preferred_email)
    • Supplemental Name Information (given_name (family_name)
    • Authentication Profiles (acr)
    • External Idenfifier (voperson_external_id)
    • SSH Keys (ssh_public_key)
    • Verified Email Address (email_verified)
    • The domain name of the users Home-Org. (org_domain (organization_name (schac_home_organization)
    • Version of the AARC Profile (aarc_ver)

Warning: Attribute names are based on an early and old draft of AARC-G056!!!












Currently Monitored Community AAIs

  • European Research Infrastructure
    • EGI Check-in, eduTEAMS, LifeScience AAI, Unity (Helmholtz)
  • German Research Infrastructure
    • RegAPP (NFDI), Bildungsproxy, academic-id, didmos
  • International Collaborations
    • WLCG IAM (High-Energy Physics), CILogon (US)




https://cvs.data.kit.edu/~naco

Use Cases

  • Compliance Monitoring
    • Continuous validation of attribute release
    • Early detection of configuration drift
  • Service Provider Onboarding
    • Verify Community AAI meets requirements before integration
  • Federation Operations
    • Compare attribute coverage across Community AAIs
    • Support standardisation efforts

The Future Is

  • Add more CAAIs
  • Ensure full AARC G056 compatibility
    • Once AARC G056 is final(ly final)
  • Board of Shame
    • (for the home-IdPs)
